PAM-2 Studiomaster Power Amplifier Power AMP for Speakers

SKU: PAM-2

In stock

exceedsound specialize in providing high-quality PAM-2 Studiomaster Power Amplifier Power AMP for Speakers for wholesale purchase. Our range of audio mixers includes compact mixers, digital mixers, analog mixers, portable mixers, studio mixers, live sound mixers, and more. Whether you’re a retailer, distributor, or reseller, our wholesale audio mixers are designed to meet your business requirements. Place your wholesale order today and enhance your success in the audio mixer market.

PAM-2 Series use particular perfect protection circuit. It's DISTORTION is less and BASS is strong, suitable for Indoor and Outdoor various shows.

Categories: Audio System, Power Amplifier Tag: 2CH

Description

Application

200 watts to 400 watts suitable for various meetings and small indoors and home KTV
500 watts to 800 watts, suitable for various medium-sized performances and KTVs
900 watts to 1300 watts, suitable for various entertainment dance halls and large outdoor stage performance
Above 1200 watts is suitable for subwoofer

Feature

Perfect protect function: boot buffer, over-current protection, short-circuit protection, over-temperature protection, output DC protection, etc.
30Hz HI PASS swith on the back panel(2U), more user-friendly
Two fanscan better help the amplifier dissipate heat to gain strong stability
30Hz HI PASS 150Hz LO-PASS and LMTER switch on the back panel(3U), more user-friendly
3U amplifier adopts thicker(6cm top and down) foams for the package to guaranttee the safety of the amplier in transit

Additional information

Product Specifications

Model	PAM-2200	PAM-2300	PAM-2400	PAM-2500	PAM-2600	PAM-2700	PAM-2800	PAM-2900	PAM-21000	PAM-21200	PAM-21300
Stereo output power 8Ω	2×200W	2×300W	2×400W	2×500W	2×600W	2×700W	2×800W	2×900W	2×1000W	2×1200W	2×1300W
Stereo output power 4Ω	2×300W	2×500W	2×700W	2×850W	2×1050W	2×1200W	2×1350W	2×1550W	2×1600W	2×1900W	2×2100W
Stereo output power 2Ω	2×500W	2×800W	2×1000W	2×1300W	2×1400W	2×1600W	2×1800W	2×2000W	2×2200W	2×2600W	2×2800W
Bridged mono output 8Ω	600W	1000W	1250W	1500W	1750W	2050W	2300W	2600W	2900W	3300W	3500W
Bridged mono output 4Ω	1000W	1300W	1700W	1950W	2300W	2750W	2900W	3400W	3800W	4200W	4400W
Frequency Response	20Hz-20KHz±0.3dB							20Hz-20KHz±0.3dB
Main input voltage	AC/190V-240V							AC/190V-240V
THD	<0.03% 8Ω 1kHz							<0.03% 8Ω 1kHz
S/N Ratio	＞90dB			＞95dB				＞95dB
Slew Rate	45V/Usec							45V/Usec
8Ω Damping Coefficient	＞300							＞300
Output Circuit	Class AB			Class H				Class H
Crosstalk Between Channels	>100dB@8Ω 1KHz							>100dB@8Ω 1KHz
Input Impedance	20kΩ(Balance)/10KΩ(Unbalance)							20k(Balance)/10KQ(Unbalance)
Input Sensitivity	0.755V/1.0V/1.4V							0.755V/1.0V/1.4V
Height	2U							3U
